Filling Plugging Capping Machine for Eyedrops Nasal Spray and Eliquid

short description:

This monobloc sterile or non-sterile filler with function of fully automatic filling, spray dropper insertion and over cap sealing. It is widely used in spray pump bottle liquid filling and packing applications. Compact design, all PLC control system by smart program and servo motor drive. Can be run stand-alone or complete line for liquid filling pharmaceutical or cosmetic industrials.

This video is for your reference,our machine can be customized according to your requirments




Product Detail

Product Tags

Product Display

spray filling (7)
spray filling (8)
spray filling (9)
spray filling (3)

Overview

This machine is mainly available to fill Oil, Eye-drop, Cosmetics oil, E-liquid, hand sanitizer, perfume, gel into various round and flat Glass bottles. High precision cam provides a regular plate to position, cork and cap; accelerating cam makes capping heads going up and down; constant turning arm screws caps; piston measures filling volume; and touch screen controls all action. No bottle no filling and no capping. The machine enjoys high position accuracy, stable driving, precise dosage, and simple operation and also protects bottle caps. Servo motor control peristaltic pump filling for less tham 50ml bottle filling,

Parameter

Applied Bottle 5-200ml customized
Productive Capacity 30-100pcs/min
Filling Precision 0-1%
Qualified stoppering ≥99%
Qualified cap putting ≥99%
Qualified capping ≥99%
Power Supply 380V,50Hz/220V,50Hz (customized)
Power 2.5KW
Net Weight 600KG
Dimension 2100(L)*1200(W)*1850(H)mm

Integrated with mechanical, electrical & pneumatic system, the monoblock design is less space-taking, reliable & stable, with high automation, espcially good for OEM, ODM products & not big scale auto production;

Features

1.The parts which contact liquid are SUS316L stainless steel and others are SUS304 stainless steel
2.Including feeder turntable,effective cost/space saving
3.It has intuitive and convenient operation, measuring accurate, positioning precision
4.Fully in accordance with the GMP standard production and passed CE certification
5. Siemens Touch screen/PLC
6.No bottle no filling/plugging/capping

The Machine Details

The filling heads can be customized based on customer's requirements and also filling system will be used that decides on the filliing material. According to the viscosity of customer's material to choose the peristalic pump filling or piston pump filling. We can also provide anti-drip design.

spray filling (8)
vial filling (5)

2) The multi roller structure of our peristaltic pump further improves the stability and non impact of filling and makes the liquid filling stable and not easy to blister. It is especially suitable for filling the liquid with high requirement.

The vibrating plate is for the inner cap and outer cap loading, it is will customize based on bottle cap, if it is only cap, just need one set of vibrating plate. It will be used to sort of different kinds of caps and send bottle into loading cap guider automatically one by one.

eye drop filling3
spray filling (5)

The cap head is in high quality and stronger, so it can screw tightly and won't damage the cap.

The bottle is fixed on the mould of disk and then it is screwed by the capping head.

Drop cap inset station that put dropper aumatically is used for dropper bottle

Dould capping station will be used for inner plug and outside cap.

One plugging station, catch plug head will suck plug and insert it into bottle mouth ,capping station will suck outside cap put into bottle mouth too.
