Automatic Tomato Sauce Paste Liquid Filling and Capping Machine

short description:

The fully automatic paste filling capping machine is with CE & ISO 9001 certification.The machine is applied to glass or plastic bottles, jars, cans, buckets with different sizes and shapes, and suitable for different filling volume. By adjusting the filling volume on touch screen, it can fill liquid with quick speed and high precision. It is widely used for tomato jam, honey, mayonnaise, fruit jam and other viscocity liquid.

This video is automatic ketchup filling machine,if you have any intersted about our products,please send an email to us


Product Detail

Product Tags

Product Display

filling nozzles
piston pump
IMG_6438

Overview

The automatic paste filling machine is mainly used in the food industry and is capable of filling accurately and rapidly any viscosity liquid such as tomato sauce,tomato paste, honey, ketchup, soy sauce, peanut butter etc. It can be used with capping machine, labeling machine and a complete production line. It integrates light, machine, electricity and gas in one. By controlling the filling time to realize the measurement of different filling, the filling time can be precisely controlled to one percent seconds. The filling process was under the control of a PLC program on the touch screen to complete. It's a filling machine with convenient operation.

Parameter

Number of filling  heads

4~20 head (depending on the designing)

Filling capacity

according to your requirment

Filling type

piston pump

Filling speed

500ml-500ml: ≤1200 bottles per hour 1000ml: ≤600 bottles per hour

Filling accuracy

±1-2g

Program control

PLC + touch screen

Main materials

304 stainless steel, 316 used in food industry

Capacity of material tank

200L (with liquid level switch)

Protective device

Outage alarm on shortage of liquid in the reservoirtank

Power source

220/380V, 50/60HZ or customized

Dimensions

1600*1400*2300 (length*width*height)

Host weight

about 900kg

Machine configuration

Frame

SUS304 Stainless steel

Parts in contact with liquid

SUS316L Stainless steel

Electrical parts


Pneumatic part


Features

1. The flow control devices of each filling head are independent of each other, precision adjustment is very convenient.

2. The material of the machine material contact part can use the food grade material according to the products feature, in line with the GMP standard.

3. With regular filling, no bottle no filling, filling quantity/production counting function etc features.

4. Convenient maintenance,no need any special tools.

5. Using drip tight filling head,no leaking.

Application

Food (olive oil, sesame paste, sauce, tomato paste, chili sauce,butter,honey etc.) Beverage( juice, concentrated juice). Cosmetics (cream, lotion,shampoo, shower gel etc) Daily chemical (dishwashing, toothpaste, shoe polish, moisturizer, lipstick, etc.), chemical (glass adhesive, sealant, white latex, etc.), lubricants, and plaster pastes for special industries The equipment is ideal for filling high-viscosity liquids, pastes, thick sauces, and liquids. we customize machine for different size and shape of bottles.both glass and plastic are OK.

sauce filling3

The Machine Details

Adopt SS304 or SUS316L filling nozzles

Accurate measurement, no splashing, no overflow

sauce filling1
piston pump

Adopts piston pump filling, high precision; The structure of pump adopts fast disassembly institutions, easy  to clean  and disinfect.

 Adopt Touch screen and PLC Control   Easy adjusted filling speed/volume   no bottle and no filling function  level control and feeding.

plc
sauce filling5

Filling head adopts rotary valve piston pump with the function of anti-draw and anti-dropping.

Company information

We focus on producing various kinds of filling production line for different products, such as the capsule, liquid, paste, powder, aerosol, corrosive liquid etc, which are widely used in different industries, including food/beverage/cosmetics/petrochemicals etc. Our machines are all customized according to customer’s product and request. This series of packaging machine is novel in structure, stable in operation and easy to operate.Welcome new and old customers letter to negotiate orders, the establishment of friendly partners. We have customers in Unites states, Middle east, Southeast Asia, Russia etc. and have gained good comments from them with the high quality as well as good service.

Order guide:
There are many types of filling machine,we need to know more details about your products in order that we can recommend the most suitable machine for you.Our questions as below:
1.What's your product?Please send one picture to us.
2. How many grams do you want to fill?
3.Do you have requirement of capacity?
